SAE100 R7
Thermoplastic hose for hydraulic applications from 70 to 210 bar (1000 to 3000 psi)
Chính sách ưu đãi đặc biệt
Tư vấn sản phẩm phù hợp
Hướng dẫn lắp đặt online
Cam kết bảo hành
Chiết khấu giá sỉ
Description
Technical details
| Part no. | DN | Inches | ID (mm) | OD (mm) | WP (bar) | BP (bar) | Safety factor | Bend radius (mm) | Weight (gr/m) | Ferrule standard | Ferrule A316L |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0660 | DN4 | 1/8 | 4.0 | 8.3 | 210 | 840 | 4:1 | 25 | 52 | SAB101 | SAB801 |
| 0661 | DN5 | 3/16 | 5.0 | 9.6 | 210 | 840 | 4:1 | 25 | 60 | SAB111 | SAB811 |
| 0662 | DN6 | 1/4 | 6.5 | 12.2 | 210 | 840 | 4:1 | 35 | 98 | SAB121 | SAB821 |
| 0663 | DN8 | 5/16 | 8.1 | 14.3 | 190 | 760 | 4:1 | 45 | 130 | SAB131 | SAB831 |
| 0664 | DN10 | 3/8 | 9.7 | 16.0 | 160 | 640 | 4:1 | 55 | 149 | SAB141 | SAB841 |
| 0665 | DN12 | 1/2 | 13.0 | 20.3 | 140 | 560 | 4:1 | 75 | 222 | SAB151 | SAB851 |
| 0666 | DN16 | 5/8 | 16.3 | 23.7 | 105 | 420 | 4:1 | 110 | 278 | SAB161 | SAB861 |
| 0667 | DN20 | 3/4 | 19.5 | 27.1 | 90 | 360 | 4:1 | 140 | 338 | SAB171 | SAB871 |
| 0668 | DN25 | 1 | 25.9 | 34.0 | 70 | 280 | 4:1 | 190 | 461 | SAB181 | SAB881 |
INNER TUBE
Polyester elastomer
REINFORCEMENT
One or two braids of synthetic fiber
COVER
Polyurethane – black – pinpricked – white inkjet branding
APPLICATIONS
Construction and agricultural equipment – Agricultural brake systems – Forklift Trucks – Articulating and telescopic booms – Aerial platforms – Scissor lifts – Cranes – General hydraulics – Industrial gases
FEATURES
Lighter more flexible and more compact than traditional R1 hoses – Bonded construction – Abrasion resistant – Limited change in length – Pin-pricked cover
Certificates
– MADE IN ITALY
