SAE 100R8
Thermoplastic hose for hydraulic applications from 140 to 420 bar (2000 to 6000 psi)
Chính sách ưu đãi đặc biệt
Tư vấn sản phẩm phù hợp
Hướng dẫn lắp đặt online
Cam kết bảo hành
Chiết khấu giá sỉ
Description
Technical details
| Part no. | DN | Inches | ID (mm) | OD (mm) | WP (bar) | BP (bar) | Safety factor | Bend radius (mm) | Weight (gr/m) | Ferrule standard | Ferrule A316L |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 0750 | DN4 | 1/8 | 4.0 | 8.0 | 420 | 1680 | 4:1 | 25 | 45 | SAB101 | SAB801 |
| 0751 | DN5 | 3/16 | 5.0 | 8.9 | 350 | 1400 | 4:1 | 30 | 52 | SAB111 | SAB811 |
| 0752 | DN6 | 1/4 | 6.5 | 11.5 | 350 | 1400 | 4:1 | 50 | 84 | SAB121 | SAB821 |
| 0753 | DN8 | 5/16 | 8.1 | 13.4 | 300 | 1200 | 4:1 | 55 | 106 | SAB131 | SAB831 |
| 0754 | DN10 | 3/8 | 9.7 | 15.5 | 280 | 1120 | 4:1 | 60 | 136 | SAB141 | SAB841 |
| 0755 | DN12 | 1/2 | 13.0 | 19.9 | 245 | 980 | 4:1 | 80 | 208 | SAB151 | SAB851 |
| 0756 | DN16 | 5/8 | 16.3 | 23.4 | 200 | 800 | 4:1 | 125 | 251 | SAB161 | SAB861 |
| 0757 | DN20 | 3/4 | 19.5 | 27.1 | 165 | 660 | 4:1 | 150 | 323 | SAB171 | SAB871 |
| 0758 | DN25 | 1 | 25.9 | 34.2 | 140 | 560 | 4:1 | 200 | 443 | SAB181 | SAB881 |
INNER TUBE
Polyester elastomer
REINFORCEMENT
One or two braids of aramid fiber
COVER
Polyurethane – black – pinpricked – white inkjet branding
APPLICATIONS
Construction and agricultural equipment – Forklift trucks – Articulating and telescopic booms – Aerial platforms – Safety and rescue equipment – Scissor lifts – Cranes – General hydraulics – Industrial gases
FEATURES
Aramid reinforcement for high pressure performance – Compact and lightweight – Bonded construction – Abrasion resistant – Extremely low change in length – Pin-pricked cover
Certificates
– MADE IN ITALY
