ANSI A92.2
Thermoplastic hose for hydraulic applications from 90 to 210 bar (1300 to 3000 psi)
Chính sách ưu đãi đặc biệt
Tư vấn sản phẩm phù hợp
Hướng dẫn lắp đặt online
Cam kết bảo hành
Chiết khấu giá sỉ
Description
Technical details
| Part no. | DN | Inches | ID (mm) | OD (mm) | WP (bar) | BP (bar) | Safety factor | Bend radius (mm) | Weight (gr/m) | Ferrule standard | Ferrule A316L |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 1660 | DN4 | 1/8 | 4.0 | 8.3 | 210 | 840 | 4:1 | 25 | 52 | SAB101 | SAB801 |
| 1661 | DN5 | 3/16 | 5.0 | 9.6 | 210 | 840 | 4:1 | 25 | 60 | SAB111 | SAB811 |
| 1662 | DN6 | 1/4 | 6.5 | 12.2 | 210 | 840 | 4:1 | 35 | 98 | SAB121 | SAB821 |
| 1663 | DN8 | 5/16 | 8.1 | 14.3 | 210 | 760 | 3.5:1 | 45 | 130 | SAB131 | SAB831 |
| 1664 | DN10 | 3/8 | 9.7 | 16.0 | 210 | 640 | 3:1 | 55 | 149 | SAB141 | SAB841 |
| 1665 | DN12 | 1/2 | 13.0 | 20.3 | 180 | 560 | 3:1 | 75 | 222 | SAB151 | SAB851 |
| 1666 | DN16 | 5/8 | 16.3 | 23.7 | 140 | 420 | 3:1 | 110 | 278 | SAB161 | SAB861 |
| 1667 | DN20 | 3/4 | 19.5 | 27.1 | 120 | 360 | 3:1 | 140 | 338 | SAB171 | SAB871 |
| 1668 | DN25 | 1 | 25.9 | 34.0 | 90 | 280 | 3:1 | 190 | 461 | SAB181 | SAB881 |
INNER TUBE
Polyester elastomer
REINFORCEMENT
One or two braids of synthetic fiber
COVER
Polyurethane – black – pinpricked – white ink-jet branding
APPLICATIONS
Mobile equipment – Articulating and telescopic booms – Aerial platforms – Scissor lifts – Cranes – General hydraulics
FEATURES
Lighter more flexible and more compact than traditional R1 hoses – Bonded construction – Abrasion resistant – Limited change in length – Pinpricked cover.
– MADE IN ITALY
